Department of Electronics and Manufacturing

Enhancing industrial competitiveness through innovative technologies that lead varying manufacturing

We are contributing to enhancing industrial competitiveness by developing advanced electronic and optical device technologies that enable both performance enhancement and significant energy savings of IT equipment, and innovative manufacturing technologies that enable energy savings, resource savings, and low cost. Moreover, we are building a highly efficient production system by combining innovative manufacturing technologies and sensing technologies based on the advanced devices.


New Research Results

Drastically Improving the Sensitivity and Inspection Area of a Thin Film Transistor (TFT) Array Inspection Technology

AIST has greatly improved the sensitivity and inspection area of a thin film transistor (TFT) array inspection technology (a gate modulation imaging technology) by combining an image processing unit that can run at a speed of about 1 gigabyte per second, a CMOS camera with about 4.15 megapixels, high-brightness LED lights, and wide view-field optics. This shortened inspection time to within 3 minutes and expanded the area to 3 cm square. AIST also made it possible to inspect storage capacitors.


Optical micrographs and gate modulation images measured in TFT defect detection mode (left) and measured in capacitor defect detection mode (right)

Development of a Novel Material for Highly Efficient Spin Control by Voltage

AIST has developed a novel iron-iridium (FeIr) magnetic material for voltage-controlled magnetic memory that achieves highly efficient spin control by voltage. It was discovered that the efficiency of spin control by voltage can be increased about three-fold by using an Ir-doped ultra-thin Fe film. In addition to the efficiency of voltage control, perpendicular magnetic anisotropy, which is important to show the scalability of voltage-torque MRAM, is also improved. The target performance for practical voltage-torque MRAM has been achieved for the first time.


Properties of the developed Ir-doped ultra-thin Fe film (red star) and a schematic of the device structure

Research Unit

Nanoelectronics Research Institute

Leading-edge device integration for data utilization with increasing volume, velocity, and variety

We lead R&D of the integrated circuits for ultralow power utilization of the ever-expanding big data, creating core technologies for the device materials and structures, fabrication processes, circuit design, and nanoscale characterization. We also develop p the methodologies to meet diversifying needs of the society and the industry for the electronics. Examples in this regard are the superconductor circuits, Minimal Fab system, Flex Power FPGA, among others. Expected R&D outputs contribute to the competitiveness of the semiconductor industry in Japan and strengthen the IT platform which is essential for the future innovations to take place.

Tunnel transistor for ultralow power data processing

Research Base

AIST Tsukuba (Central)

AIST Participating Technology Research Association

・Minimal Fab Development Association


AIST Tsukuba Central 2, 1-1-1 Umezono, Tsukuba, Ibaraki 305-8568, Japan
Tel: (029) 861-3483 / Fax: (029) 861-5088
(from outside Japan: Tel: +81-29-861-3483 / Fax: +81-29-861-5088)
Nanoelectronics Research Institute WEB site

Electronics and Photonics Research Institute

Creating innovation with electronic and photonic technologies: From theories and materials to devices and systems

Aiming for safe and sustainable society, we pursue possibility of innovative electronic and photonic technologies, and their integration. We also work toward advancement of information and communication technologies by using our knowledge.
Specifically, we are developing new technologies in optical network and interconnection by integrating electronic and photonic technologies. We are also conducting theoretical and experimental research into functional materials such as strongly correlated electron systems, superconductors, and organics as well as research into emerging devices including quantum information devices.
Moreover, we are promoting a wide range of research that includes new processing technologies based on plasma and laser, novel measurement technologies based on electrical and optical methods, and new biological sensing systems.

Research Base

AIST Tsukuba (Central, West)


AIST Tsukuba Central 2, 1-1-1 Umezono, Tsukuba, Ibaraki 305-8568, Japan
Tel: (029) 861-5338 / Fax: (029) 861-5627
(from outside Japan: Tel: +81-29-861-5338 / Fax: +81-29-861-5627)
Electronics and Photonics Research Institute WEB site

Advanced Manufacturing Research Institute

Development of advanced manufacturing technology contributing to industrial sustainability

In order to contribute the sustainability of manufacturing industry, we have researched and developed on advanced manufacturing technology. The technology covers from fundamental knowledge to integration of material, processing, design, measurement and evaluation. Concretely, it includes optimizing and hybridizing process for materials, information technology on functional design and manufacturing process, on-site measurement of process and products, agile feedback cycle for the design and process, etc. In addition, we will promote the formation of a coordination center and the construction of a new manufacturing network to combine our technology and the technology of public research organizations and regional companies.

Research Base

AIST Tsukuba (East), AIST Kyushu

AIST Participating Technology Research Association

・Technology Research Association for Future Additive Manufacturing


AIST Tsukuba East, 1-2-1 Namiki, Tsukuba, Ibaraki 305-8564, Japan
Tel: (029) 861-7012
(from outside Japan: Tel: +81-29-861-7012

AIST Kyushu

807-1 Shuku-machi, Tosu, Saga 841-0052 Japan
Tel: (0942) 81-3600
(from outside Japan: Tel: +81-942-81-3600

Spintronics Research Center

Creating innovative green IT based on spintronics

The rapid development of IT society is accompanied with a large increase in the power consumption of electronic devices. To reduce the total power consumption of IT appliances, power consumed during input "standby time" as well as active power have to be significantly reduced. To achieve this, it is essential to develop nonvolatile memory, which retains data even after the power is turned off. We are developing low-power-consuming, high-speed, and highly-reliable nonvolatile memory and spin logic device based on spintronics technology. Moreover, we are also developing novel spintronic devices such as nano-sized microwave oscillator called Spin-Torque Oscillator (STO), high-speed physical number generator named Spin Dice, and spin optical devices.

Advanced Coating Technology Reserch Center

Development of the applied surface technology for the various industrial components and products

In order to build sustainable societies, it is necessary to develop the new materials, components, and devices contributing to the environment and energy life innovation. To address such issues, Innovative green device (various battery, energy-saving devices, etc.), sensors, structural materials, will be developed by utilizing advanced coating technologies with world-leading potential such as the aerosol deposition (AD) method, excimer laser assisted metal organic deposition (MOD) method, and laser assisted ink-jet printing (LIJ) method etc. In addition, new materials development, improvement and cost reduction of the coating technology based on the elucidation of the coating mechanism will provide a bridge to the private sector in a multi-business areas by taking advantage of basic research potential of AIST.

Research Base

AIST Tsukuba (Central,East)

Research Center for Ubiquitous MEMS and Micro Engineering

MEMS technologies for smart, safe and secure society realized by sensor networks

Toward the realization of smart, safe and secure society, the IoT (Internet of Things) technology is of increasing importance. In order to realize IoT, we are working on MEMS (Micro Electro Mechanical Systems) sensor network devices and systems, and their social implementation in the application fields such as energy, agriculture, health care, automobiles and infrastructure monitoring, through the R&Ds on our core competences including low temperature bonding, nanostructure fabrication, and piezolelectric MEMS device technologies. In addition, we are attempting to improve our MEMS foundry for high-mix low-volume production of high-value added devices, and to provide capabilities of R&D, prototyping and human resources training to meet the industry needs.

Image of Research Center for Ubiquitous MEMS and Micro Engineering

Research Base

AIST Tsukuba (East)


AIST Tsukuba East, 1-2-1 Namiki, Tsukuba, Ibaraki 305-8564, Japan
Tel: (029) 861-7100 / Fax: (029) 861-7225
(from outside Japan: Tel: +81-29-861-7100 / Fax: +81-29-861-7225)
Research Center for Ubiquitous MEMS and Micro Engineering WEB site

Sensing System Research Center

Hub Center for High-Performance Sensing Toward Safe and Secure Life

In upcoming society (“Society 5.0” in a definition of the government of Japan), where everyone and everything are connected via IoT (Internet of Things), major requirements are sensing and computerizing of various events that happen in “physical space”, and its connection to “cyber space”. Targets of sensing are machine systems such as vehicles and factories, infrastructures such as roads and bridges, work and life environment, and many others. Particularly challenging are invisible objects, including threats of virus or pathogen, and comfort or pain felt with human’s body and mind. Our goal is to visualize the information both inside and outside human being, and to develop high-performance sensing technology that contributes to daily life with safety, security, and both mental and physical richness.

Research Base

AIST Tsukuba (Central)


AIST Tsukuba Central 5, 1-1-1 Higashi, Tsukuba, Ibaraki 305-8565 Japan
Tel: (029) 861-4451
(from outside Japan: Tel: +81-29-861-4451)

Cooperative Research Laboratories

In order to conduct research and development more closely related to strategies of companies, we have established collaborative research laboratories, bearing partner company names.

Partner companies provide their researchers and funding, and AIST provides research resources, such as its researchers, research facilities, and intellectual property. The loaned researchers of companies and AIST researchers jointly conduct research and development.

By setting up cooperative research laboratories, we will accelerate the commercialization of our goal-oriented basic research and application research with partner companies.

  • TEL – AIST Cooperative Research Laboratory for Advanced Materials and Processes
